Hydraulic Complete Equipment Co., Ltd
|
Single Piston Rod Welded Hydraulic Cylinders For Hydraulic Pile Driver
| Place of Origin: | Zhejiang, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
Single Piston Rod Welded Hydraulic Cylinders For Hydraulic Pile Driver
For water conservancy, mechanical/m
Single Piston Rod Welded Hydraulic Cylinders For Hydraulic Pile Driver
For water conservancy, mechanical/marine/mining equipment, oil industry, vehicles, energy and port facilities
Material :carbon, alloy, stainless steel
Certification:DNV, ABS, Lloyds, BV, SGS, GL, and CCS
AAA grade credit certificate issued by international credit assessment center
Key Specifications/Special FeaturesKey Specifications/Special Features
| Application industry | water conservancy, mechanical/marine/mining equipment, oil industry, vehicles, energy and port facilities |
| Stroke length | 50 to 16,000mm |
| Tube inner diameter | 80 to 1,050mm |
| Piston rod diameter | 45 to 600mm |
| plate | Ni/Cr/ceramic |
| Working pressure | 70 to 700 bars |
| bearing | LONGXI(china)or SKF |
| Seal type | common stand or in accordance with client's requirement (we usually use Parker from USA or MERKER from Germany) |
| valves | parker/rexroth/atos/hydcom |
| Certification | DNV, ABS, Lloyds, BV, SGS, GL, and CCS |
| Material | carbon, alloy, stainless steel |
|
Detail manufacturing drawings to be submitted to buyer for approval before manufacture is commenced |
The single piston rod hydraulic cylinder for 25MPa nominal pressure , the pistons diameterφ50-φ500mm, travel to 6m .The hydraulic cylinder have crock bottom
half rings, crock bottom hinged rings, crock bottom circular flange, cylinder head round flange, intermediate trunnion, base and so on many kinds of
installation.Piston plated hard chromium or ceramic coating.Sealing form according to the different kinds hydraulic oil requirements and the friction factor of
different selection.Still, choose according to need position measurement, analog or digital output, trunnion or piston rod extend, etc.
.
We are Changzhou Hydraulic Complete set Equipment Co., LTd, leading manufacturer for hydraulic cylinder, hydraulic servomotor, dam hydraulic hoist.
Products:full series of hydraulic cylinder, heavy duty hydraulic cylinder, hoist cylinder, oil cylinder, super size hydraulic cylinders.
30 years in manufacturing hydraulic cylinders, application for water conservancy projects, vehicles, machinery equipments, ship building, military industry and metallurgy equipments.
The only one super size cylinder manufactuer in China.
Full experience in design, produce, mounting, testing, operation and maintenance.
Cylinder max. Diameter 1200mm, stoke 16m, and annual productivity over 2000t.
Strong technological force and advanced technique and equipment, such as 3 sets of sunnen grinding machines.
2000m2 synthetic office building of computer control net work center
GB/T9001-2000, IDT ISO 9001:2000 quality management system.
AAA grade credit certificate issued by international credit assessment center
